24C 48C 96C Micro Bundle Fiber Optic Cable SM G657A1 or G657A2 for Indoor

Description

Micro bundle fiber optic cable manufactured by ANC International Co., Limited contains 6, 8 or 12 micro bundles with 2, 4, 6 or 12 fibers (each fiber diameter of 250um). These bundles are stranded around FRP central strength element and surrounded with aramid yarn as strength members. Outer sheath is LSZH material. This cable uses bend-intensive G657A1 or G657A2 or other customized fiber inside. The small bending radius of this cable makes the cable easy to arrange in patch panels, in cable trays and in FTTH.

Specification

All dielectric and dry design
Micro-bundle compact design for easy installation

Indoor cable for horizontal and vertical installations
Designed for termination by splicing
Easy mid-span entry and split out
All available in singlemode and multimode fiber, including bend insensitive fiber type
Compliant with EIA/TIA 568 and Telcordia GR-409-CORE standards
IEC 60332 Fire Retardant upon customer request
Sheath Color: Aqua (OM3-OM4), Lime Green (OM5), Yellow (OS2)

High level bend insensitivity
Reinforced by placing the Kevlar on the outside of the sub-tube

High strength aramid yarn strength member
Small outer diameter, lightweight, flame-retardant

Usage

Indoor Riser
FTTx indoor use
Distribution
Indoor access and data centers

Building to building connecting cable
Pigtails,movable connectors and patch cords for communication equipment

Technical Data

Table 1. Characteristics of the Single Mode Fiber (ref. ITU-T G657A)

48Core micro bundle cable parameters
