8Fiber MPO Female to 4 x LC Duplex Fiber Breakout Cable 50/125 OM4 3.0mm LSZH Jacket

Description:

OM4 8 Fiber 12 Fiber MPO-4xDuplex LC Connector MPO Fanout Cable Assemblies manufactured by ANC International Co., Limited have a flame retardant LSZH sheathing. OM4 MPO to 4xLC Breakout Cables are designed for the transmission of signals around 850nm, are suitable for connecting networking components with each other on optical lanes for example and have a low input loss and a high return loss. The MPO breakout fiber optic cable is comprised of one MPO female connector on one end and 4xLC duplex fiber connectors on the other end. The MPO fanout cables utilize 8 core OM4 fibers to fully transmit 40GBASE-eSR4, 4 fibers in each direction transmitting at 10Gbps. The fiber optic breakout cable conforms to Method B (Cross-Connect) polarity, and MTP® connector is available upon request. This OM4 MPO to 4xLC Duplex breakout cable is suitable for use in 100G QSFP28 SR4 to 25G SFP28 SR or 40G QSFP SR4 to 10G SFP+ SR transceiver interconnection. It is an ideal solution for data distribution in current data center; These MPO MTP fanout cable assembly can be configured with 8fiber 12 fiber, 24 fiber, MPO MTP connectors. They are available in both male and female version, and also come with LC, SC, FC and ST connectors on the fan out side. The ruggedized 2mm or 3mm furcation legs provide a more rugged solution than products with 900um legs, in turns provide excellent installation convenience and longer lifespan. This MPO Fanout cable assemblies are available in OM3, OM4 or SM fiber in lengths of 5, 10, 25 meters, custom lengths are available on request.
Single mode 9/125µm is optimized for long range (LR) distances, while multimode is only capable of short range (SR) data transfer.

Features:

Used for the transition between trunk backbone assemblies and fiber rack system;
Standard loss or Elite loss MPO/MTP optional
MPO or MTP optional
100% inteferemeter pass before shipping
100% tested for low insertion loss performance and high return loss
Factory-terminated provide consistent quality, high performance and reduce installation time
Save Time & Space
OM4 50/125μm Fiber
Comply with IEC 61754-7, TIA/EIA 604-5, Telcordia GR-1435-CORE and RoHS
LSZH Jacket by Default
Customized furcation length to cater for different installation situations
Ruggedized furcation legs: Round fanout kit with 2.0 mm or 3.0 mm legs to single-fiber connectors

Applications:

Telecommunication
Data Center
LAN, FTTX
CATV

Optical Performance:

Generic Connector Performance:

Related Product Pictures

ANC International Co., Limited is an experienced OEM & ODM manufacturer and supplier for fiber optic patch cord and pigtails, fiber optic adapters, attenuators, PLC Splitters, CWDM, DWDM, OADM, fiber switch, fiber isolator, circulator, SFP transceiver, media converter, fiber optic patch panel, termination boxes, fiber optic cleaners and tools in Shenzhen, China.

Established in year 2005, ANC has been growing with clients over pass 10 years. Right now, ANC has plastic and adapter production plant in Hangzhou, has patch cord & attenuator assembly line in Shenzhen. Its products have been selling to big companies in China and reputed clients worldwide.

ANC focus on fiber optic products only. It aims to provide high quality and low lost customized products to meet client request.
